DroneSentry-X Mk2
Wide-Area Multi-Mission Detection and Defeat
Detect Only Item Number: 211
Detect and Defeat Item Number: 210
Detect Only NSN: 5865-22-639-8187
Detect and Defeat NSN: 5865-22-639-8184
DroneSentry-X Mk2 is a software-defined detection and adaptive disruption system, designed for mobile, field expedient pop-up, and fixed site protection. Engineered for seamless integration across land, sea, and air platforms, it provides real-time drone detection and mitigation in complex operational environments.
Advantages
Mission Adaptable Modular Platform
Multiple hardware and software configurations to support customization and match the requirements of the mission.
Hemispheric Coverage
Full hemispheric detection capability with directional (cardinal) bearing target identification.
Cost-Effective Solution
Lower cost, dual-use capable solution compared to other mobile and fixed site solutions.
Features columns-t-simple
All-in-One C-UAS System
Combines detection, tracking, and adaptive disruption capabilities in a single unit.
Robust and ruggedized design to meet military durability standards with resistance to shock and vibration.
Multi-Sensor Fusion
Integrates RF, radar, and optical technologies for enhanced situational awareness.
Compatible with DroneSentry-C2
Automated or Manual Operation
Configurable for fully autonomous or operator-controlled engagement.
DroneSentry-X is supported by RFDeviceManager UI, a web-based User Interface (UI) that enables operators to view real-time analytics of local detection activity with map overlay, while supporting user-defined options for either automatic or manual disruption.
AI-Driven Threat Analysis
Rapidly identifies and responds to drone activity with minimal operator input.
Updates to DroneShield proprietary AI/ML driven detection engine ensures the DroneSentry-X is effective and constantly evolving in a rapidly changing threat environment.
Flexible Deployment
Mountable on vehicles, vessels, and static installation for dynamic protection for military, maritime, authorized law enforcement, security agencies, and critical infrastructure owners.
Provided with a ruggedized tablet to support quick access and enhanced visualization.
Ease of Use and Integration
AI-driven threat analysis enables autonomous or operator-controlled engagement with minimal training.
Open architecture design enables readiness to integrate APIs with various data output options.
DroneSentry-X is compatible with DroneLocator technology, providing real-time, mission-critical information such as drone and controller coordinates, altitude, and velocity.
Specifications columns-2
DroneSentry-X Mk2
Product Specifications
Detection and disruption on UAS (e.g. drones) operating on consumer and commercial ISM frequencies
Environment and Installation Mounting:
Compatible with most commercial roof-racks
Suitable in permanent and temporary mast installations
Dimensions:
710 x 710 x 532 mm / 28” x 28” x 21” (antenna-mounted height)
Weight:
46kg/101lbs (including brackets)
Output and Integration:
Audio + visual alerts via UI JSON, gRPC, TAK compatible
Environment
Operating Temperature
-20°C to +55°C / -4°F to +131°F
Ingress Protection:
Rated to IP67
Shipping
Packaging:
Ships in a rugged carry case (IP67)
Dimensions:
1300 x 900 x 900 mm / 51.18” x 35.43” x 35.43”
Total Shipped Weight
12.0kg / 26.46lbs (including carry case)
Warranty
12 months
12 months from date of shipment
Longer warranty available on request
Gallery gallery
Expeditionary Fixed Site (EFS) Kit
Wide-Area Multi-Mission Detection and Defeat
Item Number: 123
The Expeditionary Fixed Site (EFS) Kit transforms the DroneSentry-X Mk2 (link) into a best-in-class integrated sensor and effector solution for wide area operations. Combining DroneShield’s advanced detection and mitigation technologies, it delivers comprehensive, autonomous, and scalable, drone defense in static locations.
Advantages
Scalable System
Expandable to meet evolving protection needs.
Hemispheric Coverage
Full hemispheric detection capability with directional (cardinal) bearing target identification.
Cost-Effective Solution
Lower cost, dual-use capable solution compared to other mobile and fixed site solutions.
Features columns-t-simple
Design
Modular, ruggedized system engineered for fast deployment in urban, remote, or high-security locations.
Robust and durable carry case and cables rated to IP67 for durability in harsh environments.
Versatility
Streamlined deployment supports versatile use in scenarios including on-the-move, reconnaissance, and base defense.
360° monitoring ensures drone detection and mitigation in wide range areas.
AI Integration
Provides operators with real-time threat intelligence for rapid decision-making and responses to UxS threats.
Updates to DroneShield proprietary AI/ML driven detection engine ensures effectiveness and continuously evolving in a rapidly changing threat environment.
Mission-Adaptable
Offers various hardware and software configurations to meet mission requirements and support customization.
Portable battery solution enhances mobility in remote or temporary settings by reducing the dependency on fixed power sources.
Automated or Manual Operation
Configurable for fully autonomous or operator-controlled engagement.
DroneSentry-X is supported by RFDeviceManager UI, a web-based User Interface (UI) that enables operators to view real-time analytics of local detection activity with map overlay, while supporting user-defined options for either automatic or manual disruption.
Ease of Use and Integration
Tool-less assembly in less than 10-minutes without specialized training.
Seamlessly integrates with existing security infrastructure for scalable protection.
Specifications columns-3
Expeditionary Fixed Site (EFS) Kit
Disruption Method
Software Defined Disruption
Weight:
~70kg / ~154.3lb (DroneSentry-X Mk2, Bracket + Tripod)
Colour
Standard: Grey
User Interface
Ruggedized tablet, DroneSentry-C2 Tactical
Communications
IP Connectivity
Connects to supplied tablet
Output & Integration
Audio & Visual Alerts via UI
JSON, gRPC, TAK compatible
Cursor on Target (CoT)
Environment
Operating Temperature
-20°C to +55°C / -4°F to +131°F
Ingress Protection
Rated to IP67
(DroneSentry-X Mk2, Carry Cases, Cables)
Contents
Standard:
Rapid Deploy Kit
Tripod Kit
Standard Accessories Kit
Kit Options:
Mobility Expansion Kit
Tripod
EFS Tripod Bracket
C2 Tactical Kit
GETAC Tablet Kit
Contents
Rapid Deploy Kit
DroneSentry-X Mk2 General Assembly
Tripod Kit
Tripod
EFS Tripod Bracket
Standard Accessories Kit
Power AC Cable (US/AU/EU/UK) – 1.8m
IEC PSU Cable – 2m
HP2 PSU
Power Cable (both ends) – 15m / 50ft
Power Cable (both ends) – 4.6m / 15ft
Data Cable RJFTV (one end) – 15m / 50ft
Data Cable RJFTV (one end) – 4.6m / 15ft
Data Adaptor (RJ45 to USB)
Sensor Mounting Kit
